Thông tin chi tiết sản phẩm:
|
| Số phần: | STP240N10F7 | Loại FET: | kênh N |
|---|---|---|---|
| Xả điện áp nguồn (Vdss): | 100 V | Phí cổng (Qg) (Tối đa) @ Vss: | 176 nC @ 10 V |
| Tản điện (Tối đa): | 300W (TC) | Nhiệt độ hoạt động: | -55°C ~ 175°C (TJ) |
STP240N10F7 N-channel Power MOSFET utilizes the STripFET™ F7 technology with an enhanced trench gate structure that results in very low on-state resistance, while also reducing internal capacitance and gate charge for faster and more efficient switching.
| Parameter | Value |
|---|---|
| Product Category | MOSFETs |
| Technology | Si |
| Mounting Style | Through Hole |
| Package / Case | TO-220-3 |
| Transistor Polarity | N-Channel |
| Number of Channels | 1 Channel |
| Vds - Drain-Source Breakdown Voltage | 100 V |
| Id - Continuous Drain Current | 110 A |
| Rds On - Drain-Source Resistance | 3.2 mOhms |
| Vgs - Gate-Source Voltage | -20 V, 20 V |
| Vgs th - Gate-Source Threshold Voltage | 4.5 V |
| Qg - Gate Charge | 160 nC |
| Minimum Operating Temperature | -55 ℃ |
| Maximum Operating Temperature | +175 ℃ |
| Pd - Power Dissipation | 300 W |
| Channel Mode | Enhancement |
| Tradename | STripFET |
| Fall Time | 112 ns |
| Product Type | MOSFETs |
| Rise Time | 139 ns |
| Subcategory | Transistors |
| Transistor Type | 1 N-Channel |
| Typical Turn-Off Delay Time | 110 ns |
| Typical Turn-On Delay Time | 49 ns |
| Part Number | Package |
|---|---|
| STW65N023M9-4 | TO-247-3 |
| SH63N65DM6AG | 9-PowerSMD |
| STW70N60DM6 | TO-247-3 |
| STP65N150M9 | TO-220-3 |
| STP80N450K6 | TO-220-3 |
| STD80N240K6 | TO-252-3 |
| STW75N65DM6-4 | TO-247-3 |
| STWA70N65DM6 | TO-247-3 |
| STFW8N120K5 | TO-3PF |
| STO65N60DM6 | 8-PowerSFN |
| SCTWA20N120 | TO-247-3 |
| STB41N40DM6AG | TO-263-3 |
| STWA75N65DM6 | TO-247-3 |
| STH47N60DM6-2AG | TO-263-3 |
| STL325N4LF8AG | 8-PowerVDFN |
| SCTWA90N65G2V-4 | HiP247-4 |
| STWA65N60DM6 | TO-247-3 |
| STW48N60M6-4 | TO-247-4 |
| STHU32N65DM6AG | TO-263-8 |
| STH12N120K5-2AG | TO-263-3 |
| STFW40N60M2 | TO-3PF |
| STWA20N95K5 | TO-247-3 |
| STB30N65DM6AG | TO-263-3 |
| STW45N60DM2AG | TO-247-3 |
| STW75N60M6-4 | TO-247-4 |
| SCTH40N120G2V7AG | TO-263-8 |
| SCTWA35N65G2VAG | TO-247-3 |
| STPSC10H12CWL | TO-247-3 |
| STPSC20065WY | DO-247-2 |
| STPSC30H12CWL | TO-247-3 |
Yes, all products are original, new original import is our purpose.
We are ISO 9001:2015 Certified Company and member of ERAI.
Yes, we support sample order and small order. Sample cost is different according to your order or project.
We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
