TCAN1042HGVDR Integrated Circuit Chip 5Mbps Fault Protected CAN Transceiver SOIC-8

TCAN1042HGVDR Integrated Circuit Chip 5Mbps Fault Protected CAN Transceiver SOIC-8​

Product Description Of TCAN1042HGVDR

TCAN1042HGVDR is a fault-tolerant CAN FD transceiver designed for high-speed communication in automotive and industrial applications. It is compatible with the ISO 11898-2:2016 and ISO 11898-5:2007 standards, supports ‘Turbo CAN’ data rates of up to 5 Mbps, and incorporates robust bus fault protection and ESD protection, enabling stable operation in harsh electrical environments.

Specification Of TCAN1042HGVDR

Features Of TCAN1042HGVDR

• I/O Voltage range supports 3.3 V and 5 V MCUs
• Ideal passive behavior when unpowered
– Bus and logic terminals are high impedance (no load)
– Power up/down with glitch free operation on bus and RXD output
• Protection features
– HBM ESD protection: ±16 kV
– IEC ESD protection up to ±15 kV
– Bus Fault protection: ±58 V (non-H variants) and ±70 V (H variants)
– Undervoltage protection on VCC and VIO (V variants only) supply terminals
– Driver dominant time out (TXD DTO) - Data rates down to 10 kbps
– Thermal shutdown protection (TSD)
• Receiver common mode input voltage: ±30 V
• Typical loop delay: 110 ns
• Junction temperatures from –55°C to 150°C

Applications Of TCAN1042HGVDR

• All devices support highly loaded CAN networks
• Heavy machinery ISOBUS applications – ISO 11783
• Industrial automation, control, sensors and drive systems
• Building, security and climate control automation
• Telecom base station status and control
