Thông tin chi tiết sản phẩm:
|
| Part Number: | 170340-3026 | Number of Positions: | 192 Position |
|---|---|---|---|
| Number of Rows: | 12 Row | Current Rating: | 750 mA |
| Component Type: | PCB Receptacle | Voltage - Maximum: | 30V AC (RMS)/DC |
| Làm nổi bật: | 192POS modular backplane connectors,impact backplane connectors 170340-3026,modular connectors with 192 positions |
||
| Part Number | 170340-3026 |
| Number of Positions | 192 Position |
| Number of Rows | 12 Row |
| Current Rating | 750 mA |
| Component Type | PCB Receptacle |
| Voltage - Maximum | 30V AC (RMS)/DC |
170340-3026 Impact Backplane Connectors - Impact 85 Ohm Plus 4 Pair, Right-Angle Daughtercard, Left Guided, 16 Columns, 192 Circuits, Plated Through Hole Dimension 0.39mm, Lead Free.
| Series | Impact 170340 |
| Packaging | Tray |
| Part Status | Active |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | Impact, Guide Left |
| Number of Positions | 192 |
| Number of Rows | 12 |
| Number of Columns | 16 |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Termination | Press-Fit |
| Contact Layout, Typical | 64 Differential Pairs |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Color | Gray |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -55°C ~ 85°C |
| Voltage Rating | 30V |
| Part Number | Package |
|---|---|
| TMC5072-LA | 48-QFN |
| CS46L41-CWZR | WLCSP |
| PI2DBS16212AZREX | 24-TQFN |
| STM32L4A6VGT6 | 100-LQFP |
| ISL9238CIRTZ | 32-TQFN |
| ISL9238CHRTZ | 32-TQFN |
| RAA489800ARGNP | 32-TQFN |
| TPS62135RGXR | 11-VQFN |
| ISL9238 | 32-TQFN |
| RAA489800 | 32-TQFN |
| TPS62135 | 11-VQFN |
| MT62F1G64D8WT-031 | 496-FBGA |
| TMC5072 | 48-QFN |
| CS46L41 | WLCSP |
| PI2DBS16212 | 24-TQFN |
| AGFB014R24D1I3V | 2340-BGA |
| AGFB008R16A2I2VB | 1546-BGA |
| AGFD023R31C2E3E | 3184-BGA |
| AGFB012R24C2I3E | 2340-BGA |
| AGFB014R24C2I2V | 2340-BGA |
| AGFD023R25A3E3E | 2581-FBGA |
| AGID019R31B1I1VB | 3184-BGA |
| AGFB019R31C2E2VB | 3184-BGA |
| AGFD023R24C2E1VB | 3184-BGA |
| AGFB019R24C2I1V | 2340-BGA |
| AGFB023R24C2E1V | 2340-BFBGA |
| AGIB027R29B1E2V | 2957-BGA |
| AGIB027R31A2E2V | 3184-BGA |
| AGFB019R24C3I3E | 2340-BFBGA |
| AGFB008R24C2E2VB | 2340-BGA |
A: Yes, all products are original, new original import is our purpose.
A: We are ISO 9001:2015 Certified Company and member of ERAI.
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
