Thông tin chi tiết sản phẩm:
|
| Part Number: | ISO7721QDRQ1 | Voltage - Isolation: | 3000Vrms |
|---|---|---|---|
| Data Rate: | 100Mbps | Rise / Fall Time (Typ): | 1.8ns, 1.9ns |
| Voltage - Supply: | 2.25V ~ 5.5V | Operating Temperature: | -40°C ~ 125°C |
| Làm nổi bật: | ISO7721QDRQ1 digital isolator chip,dual channel digital isolator SOIC8,3000Vrms isolated IC chip |
||
ISO7721QDRQ1 Integrated Circuit Chip 3000Vrms Dual Channel Digital Isolators SOIC8
Product Overviews Of ISO7721QDRQ1
ADG726BCPZ is monolithic, complementary metal oxide semiconductor (CMOS) 32-channel and dual 16-channel analog multiplexers. ADG726BCPZ switches one of 16 inputs as determined by the 4-bit binary address lines A0, A1, A2, and A3.
Specification Of ISO7721QDRQ1
| Part Number: | ISO7721QDRQ1 |
| Product Category: | Digital Isolators |
| SMD/SMT | |
| SOIC-8 | |
| 2 Channel | |
| Unidirectional | |
| 100 Mb/s | |
| 3000 Vrms | |
| Capacitive Coupling | |
| 5.5 V | |
| 2.25 V | |
| 7.3 mA | |
| 17 ns | |
| - 40 ℃ | |
| + 125 ℃ | |
| Forward Channels: | 1 Channel |
| Maximum Fall Time: | 3.9 ns |
| Maximum Rise Time: | 3.9 ns |
| Pd - Power Dissipation: | 100 mW |
| Product Type: | Digital Isolators |
| Pulse Width Distortion: | 0.5 ns |
Features Of ISO7721QDRQ1
100 Mbps data rate
Robust isolation barrier:
– >30-Year projected lifetime at 1.5 kVRMS working voltage
– Up to 5000 VRMS Isolation Rating
– Up to 12.8 kV surge capability
– ±100 kV/μs Typical CMTI
Wide supply range: 2.25 V to 5.5 V
2.25-V to 5.5-V level translation
Default output High (ISO772x) and Low (ISO772xF) Options
Low power consumption, typical 1.7 mA per channel at 1 Mbps
Low propagation delay: 11 ns typical
Robust electromagnetic compatibility (EMC)
– System-Level ESD, EFT, and surge immunity
– ±8 kV IEC 61000-4-2 contact discharge protection across isolation barrier
– Low emissions
Applications Of ISO7721QDRQ1
Hybrid, electric and power train system (EV/HEV)
– Battery management system (BMS)
– On-board charger
– Traction inverter
– DC/DC converter
– Inverter and motor control
