Thông tin chi tiết sản phẩm:
|
| Part Number: | LT3970IDDB-3.3 | Voltage - Input (Min): | 4.2V |
|---|---|---|---|
| Voltage - Input (Max): | 40V | Voltage - Output (Min/Fixed): | 3.3V |
| Current - Output: | 350mA | Frequency - Switching: | 200kHz ~ 2.25MHz |
LT3970IDDB-3.3 Integrated Circuit Chip Step Down Regulator 40V Buck Switching Regulator
Product Overviews Of LT3970IDDB-3.3
LT3970IDDB-3.3 is an adjustable frequency monolithic buck switching regulator that accepts a wide input voltage range up to 40V, and consumes only 2.5μA of quiescent current. A high efficiency switch is included on the die along with the catch diode, boost diode, and the necessary oscillator, control and logic circuitry.
Specification Of LT3970IDDB-3.3
| Part Number: | LT3970IDDB-3.3 |
| Product Category: | Switching Voltage Regulators |
| SMD/SMT | |
| DFN-10 | |
| Buck | |
| 3.3 V | |
| 350 mA | |
| 1 Output | |
| 4.2 V | |
| 40 V | |
| 1.8 uA | |
| 200 kHz to 2.2 MHz | |
| - 40 ℃ | |
| + 125 ℃ | |
| Input Voltage: | 4.2 V to 40 V |
| Operating Supply Current: | 1.7 uA |
Features Of LT3970IDDB-3.3
Low Ripple Burst Mode Operation
2.5µA IQ at 12VIN to 3.3VOUT
Output Ripple < 5mVP-P
Wide Input Voltage Range: 4.2V to 40V Operating
Adjustable Switching Frequency: 200kHz to 2.2MHz
Integrated Boost and Catch Diodes
350mA Output Current
Fixed Output Voltages: 3.3V, 3.42V, 5V; 1.8μA IQ at 12VIN
Accurate 1V Enable Pin Threshold
Low Shutdown Current: IQ = 0.7μA
Internal Sense Limits Catch Diode Current
Power Good Flag
Output Voltage: 1.21V to 25V
Internal Compensation
Applications Of LT3970IDDB-3.3
Automotive Battery Regulation
Power for Portable Products
Industrial Supplies
